I need to design a industrial shed of 25'-0" height and truss span is 200' with

Sat Nov 24, 2018Total posts : 1
Er.S.K.Jain
Er.S.K.Jain
Join date: May 2015
Topic: I need to design a industrial shed of 25'-0" height and truss span is 200' with

I need to design a industrial shed of 25'-0" height and truss span is 200' with a support column in middle.I required to provide I-Beam for column without concrete. Question is which is better single I-beam section or group of two or four I-beam section for support of tubular truss. If possible standard design drawing of truss and steel column
Fri Nov 30, 2018Post  #1
S L Gupta (Civil Engg)
S L Gupta (Civil Engg)

Join date: Mar 2008
 Dear Sir,
         Please contact any structure desigen engineer for this job.
       Thanks
