Water Supply and Various Types of Pipes

Water supply is the process of general requirement for supply of water from public water supply system to individual building and subsequent distribution of water to various parts of the building. The water from public water supply system to individual buildings is supplied through pipes. A large proportion of capital is invested on pipes while designing water supply distribution system. The following factors should be considered in selection of pipes.

  •  Strength of pipe
  •  Water carrying capacity
  •  Life and durability of pipe
  •  Expenditure on transportation
  •  Jointing process, maintenance and repairs.

Various Types of Pipes

The pipes are available in several types and sizes. They may be classified into three groups according to the material used in their manufacturing.

  •  Metallic pipes: the pipes such as CI Pipes, Steel pipes and GI Pipes.
  •  Cement Pipes: the pipes such as Cement Pipes, Asbestos cement (AC) pipes, cement concrete pipes.
  •  Plastic Pipes: the pipes such as Un-plasticized PVC (UPVC ) pipes, Polythene Pipes (low denisity)
    1. Cast Iron (CI) Pipes

      These pipes are mostly used in water supply. They are well suited for pressure and can withstand external load because of their thickness. The pipes are easy in manufacturing, layout and joining. These pipes are manufactured by vertical casting in sand moulds, horizontal casting in sand moulds and centrifugal casting (spun casting pipes).

      Cast iron plumbing pipes

      (This picture is contributed by "Kumar")

      CI Pipes - Strong and heavy.

      CI pipes are heavy in weight. Therefore transportation is costlier and they are not suitable for inaccessible places. Due to heavy weight these are generally made in short length. This increases layout and jointing cost. CI vertical casting pipes are not of very good quality and can be replaced by centrifugal casting (spun casting) pipes.


      Steel Pipes

      These pipes are extensively used for water supply. They are best suitable for long distance pipe lines of high pressure and provide satisfactory performance during service. These pipes have excellent mechanical properties and are ideally suited for welding. The pipes are made in length more than twice the length of CI pipes; which saves in transport, layout of pipe and joining cost. There is minimum damage to the pipes in transportation. The pipes being light in weight are used for large diameter pipe lines.

      Cement Pipes

      Main advantage of cement pipes in place of metallic pipes is their corrosion resistance. These pipes are bulky, heavy and require careful transportation and handling. The layout process of these pipes is costlier than steel pipes.


      Asbestos Cement (AC) Pipes

      These pipes are light in weight and easy in transportation and layout. They have smooth internal surface and are not affected by corrosion (rust). The pipes are extensively used for water supply systems. Holes can be drilled in these pipes. These pipes are not costlier.


      Un-plasticized PVC (UPVC) Pipes

      These pipes are rigid PVC pipes. They are light in weight, tough, resistant to chemical attack and large in length. Due to large in length the cost of handling is much whereas transportation and installation cost is less. Smooth internal surface of pipes provide less friction which results in saving of energy. These pipes are not suitable for the area which is very hot.

      PVC plumbing pipes

      (This Picture is contributed by "Ahmed")

      PVC Pipes - Light weight still powerfull.



      ;
